SMT Three Phase Four Wire Smart Eletric Meter with Phase Loss Indicator Function

Description:
DTS150-FEW, three phase four wire electric meter in accordance with the standard of
GB/T17215.321-2008, it adopts advanced SMT production process design, LCD display. And it is used
to measure three-phase active energy, with phase loss indicator function, power off and RS485 / WiFi
communication function.

1. Mian Function and Features:
1.1 Measuring the total active energy and each split phase energy accurately.
1.2 With remote digital pulse output capability, the corresponding centralized meter reading system can
be configured to monitor the working status of the meter in real time.
1.3 Imported single-chip microcomputer control, fully digital metering, smart antistealing.
1.4 Three phase simultaneous power supply, as long as one phase has electricity, the meter can work
normally; At the same time, it has phase loss display function.
1.5 It has a two-wire RS485 communication interface and a WiFi communication interface.
1.6 Remote control.
1.7 The display mode is LCD display, which can display 6+2(six-digit integer and two decimal places).
1.8 The communication protocol complies with DL/T645-2007 and the "Digital Energy Meter RS485
Interface Communication Protocol (RDK02.0 Hubei Province-2007)" and meets the communication
requirements of the 485 meter for the centralized meter reading system of Hubei low-voltage power users.
The RS485 communication wave rate is 1200bps, 2400bps, 4800bps, 9600bps, and the WiFi
communication baud rate is fixed at 9600bps.
1.9 The meter can be cleared 5 times during use, and can not be cleared after 5 times.
1.10 The meter has the function of WiFi module timing report data and WiFi timer restart.

2. Specification and Parameters:

3. Wiring Diagram

4. Appearance

Advantages:
Reliable Design: It is a generation of products with keypad to input encrypted numbers, STS compliant.
Standard: IEC 62052-11, IEC 62053-21, IEC 62056-21
Anti-Tampering Detection: Terminal cover and top cover open detection.
Resistance on High frequency jamming circuit
Prevention of Missing Potential
Resistance on neutral disturbance
Using uni-directional counter system
